SuperATV Rhino 2.0 Big Lift Kit Axles are extended-length front and rear axles for the 2016-2021 Polaris RZR XP Turbo and XP 4 Turbo running the RZR XP Turbo 10" Lift Kit. SuperATV rates them 100% stronger than stock, with a 4mm larger shaft and maximized CVs built to handle the angles of a 10" lift.
High-strength 4340 chromoly is heat treated to SuperATV's formula for strength and longevity, and the shaft is designed to flex and return rather than pass shock into the differential. Choose Front or Rear; each axle is sold individually.
These rzr xp turbo lift kit axles are sized for a 10" rzr xp turbo lift kit or polaris rzr xp turbo lift kit, including the rzr xp 4 turbo lift kit. If you are running a rzr turbo lift kit at 10", stock rzr xp turbo axles and rzr turbo axles will not reach, so these rzr turbo 10 inch lift kit axles are the fix for a lifted rzr xp turbo or polaris rzr xp turbo.
Key Features
- Extended length for the RZR XP Turbo 10" Lift Kit
- 100% stronger than stock, per SuperATV
- A massive 4mm increase in shaft size
- Maximized CV and components
- 4340 chromoly with a proprietary heat treatment
- Field and lab tested; CAD drawn for precision
- Industry-leading 18-month warranty
Built To Solve: Stock-Length Axles on a 10" Lifted RZR XP Turbo
- Stock axles overextended by a 10" lift
- CVs overheating on high-angle mud and rock rides
- Turbo torque breaking OE axles
- Replacing a broken axle with another stock-length part
Best For: RZR XP Turbo and XP 4 Turbo Owners on a 10" Lift
- 2016-2021 Polaris RZR XP Turbo owners
- 2016-2021 Polaris RZR XP 4 Turbo owners
- Not for stock-height machines
- Not for ABS-equipped machines
Specifications
- Brand: SuperATV
- Product line: Rhino 2.0 Heavy-Duty Axle
- Material: 4340 chromoly steel, proprietary heat treatment
- Strength: 2x stock (per SuperATV)
- Warranty: 18 months
- Shaft size: 4mm larger than stock
- Length: extended for the RZR XP Turbo 10" Lift Kit
- Sold: individually, front or rear
- Manufacturer Part Number (front): AX01-027F-2
- Manufacturer Part Number (rear): AX01-017R2
Fitment
- Polaris RZR XP Turbo: 2016-2021
- Polaris RZR XP 4 Turbo: 2016-2021
Not compatible with Anti-Lock Brake Systems (ABS). Only works with the RZR XP Turbo 10" Lift Kit. Rear axles may require minor grinding on Turbo models; see the instructions below. SuperATV does not publish OEM cross-reference numbers for these axles. Fitment is not guaranteed on applications not listed above; confirm your year, model and cab before ordering.
FAQ
Do these fit a stock-height RZR XP Turbo?
No. SuperATV says they only work with the RZR XP Turbo 10" Lift Kit. For stock height, see our Polaris RZR XP Turbo Rhino 2.0 listing.
Do they fit the RZR XP 4 Turbo?
Yes. SuperATV lists the 2016-2021 RZR XP Turbo and XP 4 Turbo.
Do I have to grind anything on a Turbo?
Possibly. SuperATV says the rear axles may need minor grinding on Turbo models: its instruction sheet shows grinding the rib on the passenger side of the transmission to leave at least a 2mm (.078") gap. The sheet is linked below.
Are front and rear the same part?
No. Front (AX01-027F-2) and rear (AX01-017R2) are different axles, sold individually.
Do they work with ABS?
No. SuperATV lists these axles as not compatible with Anti-Lock Brake Systems (ABS).
What warranty do they carry?
SuperATV backs Rhino 2.0 axles with an 18-month warranty, longer than the one-year norm SuperATV cites for the industry.
Why SuperATV
SuperATV designs, engineers, manufactures and tests its Rhino 2.0 axles in-house, using CAD analysis, lab testing and real-world trail testing before release. Every Rhino 2.0 axle is backed by SuperATV's 18-month warranty, longer than the one-year norm SuperATV cites for the industry.
Complete Your Lifted RZR XP Turbo Driveline
When one RZR XP Turbo axle fails, the others have usually seen the same abuse, so decide which positions you need. Confirm your model, year and variant against the fitment list and that you are running the RZR XP Turbo 10" Lift Kit, and make sure the machine does not have ABS.
