Metal FX Destroyer R Forged 3-Piece Beadlock 17" UTV Wheel 5x4.5

The Metal FX Destroyer R Forged 3-Piece Beadlock is a true beadlock UTV wheel for the Polaris RZR Pro R, Turbo R, Pro S, XPedition and Ranger XD 1500, built on a 5x114.3 (5x4.5) bolt pattern in 17x7. It is a forged 3-piece wheel with hidden assembly bolts, a 6061-T6 billet center, a beadlock ring and a center cap, made in the USA, built from 6061-T6 billet and spun forged aluminum and offered in Custom and Raw finishes.

Metal FX rates this wheel at 1,300 lb per wheel and lists it at 25.5 lb, wheel only. Metal FX positions the Destroyer R 3-piece for dunes and desert riding. If you are shopping UTV forged wheels or custom beadlock wheels rather than a cast wheel with a forged ring, this is the step up. Among RZR Pro R beadlock wheels and Pro R beadlock wheels, it is drilled for the 5-lug hub, so it suits RZR Pro R wheels, RZR Turbo R wheels and Polaris XPedition wheels shoppers alike.

Key Features

• Forged 3-piece construction in 6061-T6 billet and spun forged aluminum
• True beadlock: the ring mechanically clamps the tire's outer bead
• 5x114.3 (5x4.5) bolt pattern
• Size: 17x7 at +32mm (5+2), 5.25 inches of backspacing
• Load rating: 1,300 lb per wheel (Metal FX)
• Finishes: Custom and Raw
• Made in the USA

Built To Solve: Bent Wheels and Unseated Tires on 5-Lug Polaris UTVs

• Tires rolling off the bead when aired down for traction
• Cast wheels that bend or crack under hard hits
• Matching a premium wheel to a 5-lug hub
• Choosing a width without knowing the offset and backspacing
• Wanting a custom color instead of an off-the-shelf finish

Best For: RZR Pro R, Turbo R and XPedition Owners

• RZR Pro R, Turbo R, Pro S, XPedition and Ranger XD 1500 owners shopping forged beadlock wheels
• Riders comparing 5x4.5 beadlock wheels and other Polaris beadlock wheels built for the 5-lug hub
• Riders who air down for dunes, desert and rocks and want the bead held in place
• Owners shopping 17 beadlock wheels and 17in beadlock wheels for a 5-lug Polaris
• Builders who want a custom-color wheel to match the machine
• Owners comparing utv forged wheels against cast beadlocks
• Riders who only need a cast wheel should look at the Metal FX Delta R Beadlock instead

Specifications

• Construction: forged 3-piece
• Center profile: concave
• Material: 6061-T6 billet aluminum and 6061-T6 spun forged aluminum
• Type: true beadlock
• Size and offset: 17x7 at +32mm (5+2), 5.25 inches of backspacing
• Bolt pattern: 5x114.3 (5x4.5)
• Center bore: 66.1mm
• Load rating: 1,300 lb (Metal FX)
• Wheel weight: 25.5 lb (wheel only)
• Finishes: Custom (Metal FX contacts you after the order to confirm colors); Raw (bare machined aluminum)
• Lug nuts: acorn-style, sold separately
• Made in the USA
• Manufacturer Part Numbers: 39258 (17x7, 5x114.3)

Fitment

Metal FX engineers the R series for Polaris 5-lug machines on the 5x114.3 (5x4.5) pattern with a hub-centric 66.1mm bore. Metal FX lists:

• Polaris RZR Pro R
• Polaris RZR Pro S
• Polaris RZR Turbo R
• Polaris XPedition XP and XPedition ADV
• Polaris Ranger XD 1500

Fitment is not guaranteed on applications not listed here. Confirm overall vehicle width with your chosen tires before ordering.

FAQ

Will the Metal FX Destroyer R Forged 3-Piece fit my Polaris RZR Pro R?

Yes. Metal FX lists it for the RZR Pro R, Pro S, Turbo R, XPedition XP and ADV, and Ranger XD 1500, all on the 5x114.3 (5x4.5) pattern with a 66.1mm bore. 4-lug RZR models use a different pattern and will not fit.

What is the difference between forged and cast Metal FX wheels?

Metal FX's cast wheels pair an A356-T6 cast wheel with a forged 6061-T6 ring. The Destroyer R Forged 3-Piece is forged throughout, from 6061-T6 billet and spun forged aluminum, and Metal FX rates it at 1,300 lb per wheel. Forged wheels carry their own part numbers and cost more.

What size and offset is the Destroyer R Forged 3-Piece?

This listing carries 17x7 at +32mm (5+2), 5.25 inches of backspacing. Center bore is 66.1mm. Metal FX also lists a 17x10 Destroyer R (39261); this listing carries the 17x7 (39258).

How does the Custom finish work?

Pick Custom and Metal FX contacts you after the order is placed to confirm your colors. Raw is bare machined aluminum.

Is it a true beadlock?

Yes. The beadlock ring mechanically clamps the tire's outer bead to the wheel, which helps keep the tire seated at lower pressures. Torque the ring bolts to spec and recheck them after the first ride.

What lug nuts does the Destroyer R need?

It takes acorn-style lug nuts, sold separately. On the RZR Pro R, Turbo R, XPedition and Ranger XD 1500, the Valor Offroad 12x1.5 5-lug kit fits.

Why Metal FX

Metal FX designs its forged wheels around specific platforms, with each model drilled for a specific platform: a 4-lug line, an R line for Polaris's 5-lug machines and a 6R line for the Can-Am Maverick R. Among Metal FX UTV wheels, the forged UTV wheels sit above the cast line. The Destroyer R Forged 3-Piece is the forged counterpart to the Metal FX cast beadlocks, with its own part numbers. Metal FX also lists a 17x10 Destroyer R (39261); this listing carries the 17x7 (39258).

Complete Your 5-Lug Polaris Forged Wheel Setup

Choose your finish, then match a tire size and check overall width before you order the Metal FX Destroyer R Forged 3-Piece. Add an acorn-style lug kit, such as the Valor Offroad 12x1.5 5-lug kit.
